Description

A JIS F3060 valve is a specific type of angle pattern globe valve made from cast steel, primarily designed for high-pressure marine and industrial piping systems. Its core function is to provide positive shut-off against high-pressure fluids (primarily water, oil, or steam) while directing flow through a 90-degree change in direction.

Advantages

• Saves Space & Fittings: Integrates a 90-degree turn into the valve body.

• High Pressure/Temperature Rating: Cast steel construction handles pressures and temperatures beyond bronze valves.

• Robust & Reliable: Designed for the demanding marine environment with vibration, pressure surges, and corrosion.

• Positive Shut-off: Provides reliable isolation for maintenance or in an emergency.

• Standardized: JIS F3060 ensures interchangeability and compliance with classification society rules (often approved by ClassNK, Lloyd's, ABS, etc.).

Drawing

Elementary Dimensions
